RADIOMASTER ER6 2.4GHz ELRS PWM Receiver
170 AED
- 6-Channel PWM Receiver for fixed-wing and RC applications
- 2.4GHz ExpressLRS with fast response and reliable link quality
- Dual Antenna Diversity with up to 100mW telemetry power
- CRSF / SBUS Support plus Wi-Fi and WebUI configuration
- Compact 14.5g Design with 4.5–8.4V input and 43 × 25 × 15mm size
| Brand | DJI |
|---|---|
| Connectivity & Setup | CRSF / SBUS serial output; Wi-Fi updates; WebUI configuration; 4-pin CRSF expansion |
| Size & Compatibility | 43 × 25 × 15mm; approx. 14.5g; 20cm antennas; compatible with 2.4GHz ELRS transmitters |
📡 Product Overview
RadioMaster ER6 2.4GHz ELRS PWM Receiver is a six-channel receiver designed primarily for fixed-wing aircraft and other models that use conventional PWM servos. Built around the ExpressLRS system, it combines responsive control, adjustable telemetry power, dual antennas, voltage telemetry, and a durable moulded enclosure.
The ER6 provides six PWM outputs alongside CRSF and SBUS serial output options. It also includes a four-wire CRSF interface for compatible telemetry sensors and future system expansion.
⚡ Key Features
- Six PWM Channels
Directly controls up to six compatible servos or other PWM devices. - ExpressLRS 2.4GHz
Compatible with RadioMaster and other transmitters or modules operating on the 2.4GHz ExpressLRS protocol. - Dual High-Sensitivity Antennas
Uses two 20cm antennas to improve signal reception when positioned correctly in the model. - Up to 100mW Telemetry Power
Telemetry output power can be adjusted through a compatible ExpressLRS Lua script. - Receiver and Flight-Battery Telemetry
Reports receiver supply voltage or external flight-battery voltage and automatically detects the available voltage input. - CRSF and SBUS Output
Supports serial output for compatible flight controllers and other equipment. - CRSF Expansion Interface
Includes a reserved four-pin CRSF connection for compatible telemetry sensors. - Wi-Fi Updates and WebUI
Supports wireless firmware updates and browser-based ExpressLRS configuration. - Durable Receiver Case
The one-piece moulded enclosure protects the internal electronics during installation and normal RC use. - Standard 2.54mm Connectors
Provides familiar servo-style connections for straightforward fixed-wing installation.
📦 Technical Specifications
- Brand
RadioMaster - Model
ER6 - Receiver Protocol
ExpressLRS 2.4GHz - Preinstalled ExpressLRS Version
ExpressLRS 3.3.0 - PWM Outputs
6 channels - Serial Outputs
CRSF and SBUS - Bus Interface
CRSF - Receiver Supply Voltage
DC 4.5–8.4V - External Battery Voltage Detection
DC 4.0–35V - Telemetry Power
Up to 100mW, Lua-adjustable
- Antenna Type
Dual 20cm high-sensitivity antennas - Dimensions
43 × 25 × 15mm - Weight
Approximately 14.5g - Firmware Category
RadioMaster 2.4GHz - Firmware Target
ER6 2.4GHz Diversity+6xPWM RX - Recommended Application
Fixed-wing aircraft and other PWM-controlled RC models
Important: The receiver itself accepts only 4.5–8.4V. The separate telemetry input can measure a flight battery between 4.0V and 35V. Do not connect a higher-voltage flight battery directly to the receiver’s normal power input.
✈️ Ideal Use Cases
- Fixed-wing RC aircraft
- Powered gliders
- Scale aircraft
- Models requiring up to six PWM channels
- ELRS aircraft requiring battery-voltage telemetry
- Compatible flight-controller installations using CRSF or SBUS
📦 Package Includes
- 1 × RadioMaster ER6 2.4GHz ELRS PWM Receiver
- 1 × Type-B Voltage Telemetry Wire
- 1 × CRSF Wire
- 1 × ELRS Receiver-to-SBUS Wire
- 1 × User Card
❓ Frequently Asked Questions
How many servos can the ER6 control?
It provides six PWM channels and can directly control up to six compatible PWM devices, subject to the model’s power-system capacity.
Does it work with an ELRS 900MHz transmitter?
No. This receiver operates on 2.4GHz and requires a compatible 2.4GHz ExpressLRS transmitter or module.
Does the ER6 include a variometer?
No. The standard ER6 does not contain a barometric variometer. RadioMaster offers other ER-series models for applications requiring a built-in vario.
Can it measure the flight battery voltage?
Yes. The included Type-B telemetry wire can measure an external battery voltage from 4.0V to 35V when connected correctly.
Can the receiver be powered from a 6S battery?
No. Its normal power input accepts 4.5–8.4V. A suitable regulated BEC is required when the model uses a higher-voltage flight battery.
Does it support CRSF and SBUS?
Yes. In addition to its six PWM channels, the ER6 supports CRSF and SBUS serial outputs.
Can its firmware be updated wirelessly?
Yes. The ER6 supports ExpressLRS Wi-Fi firmware updates and WebUI configuration.
Is it compatible with every RadioMaster transmitter?
It works with RadioMaster transmitters that have an internal 2.4GHz ExpressLRS module or a compatible external 2.4GHz ELRS module. Multi-protocol-only transmitters require a separate ELRS module.
